Components |
Center Fascia Panel Components and Components Location
Component Location
1. Center fascia upper panel2. Center fascia lower panel
...
ETC (Electronic Throttle Control) System Specifications
Specification
[Throttle Position Sensor (TPS)]
Throttle angle(°)Output Voltage (V)TPS1TPS200.54.5100.964.05201.413.59301.873.14402.322.68502.782.23603.231.77703.691.32804.140.86904.60.41984.650.35 ...
Height Sensor Schematic Diagrams
Circuit diagram
1.
Height sensor connector
2.
Height sensor terminal function
TerminalFunction1Height Sensor Ground2-3-4-5Height Sensor Power 6Height Sensor Signal
3.
Circuit diagram ...
