Have engine oil and filter changed by an authorized EQUUS dealer according to the Maintenance Schedule at the beginning of this section.
CALIFORNIA PROPOSITION 65 WARNING
Engine oil contains chemicals known to the State of California to cause cancer, birth defects and reproductive harm. Used engine oil may cause irritation or cancer of the skin if left in contact with the skin for prolonged periods of time. Always protect your skin by washing your hands thoroughly with soap and warm water as soon as possible after handling used oil.
Schematic Diagrams
Schematic Diagram
...
Steering Wheel Remote Controller (SWRC) Repair procedures
Inspection
1.
Check for resistance between terminals in each switch position.
[LH Top (Audio)]
SwitchConnectorterminalResistance(±5%)Volume Down6-7240 xSeek Down510 xMode940 xVolume Up1.69 kxSee ...
Height Sensor Schematic Diagrams
Circuit diagram
1.
Height sensor connector
2.
Height sensor terminal function
TerminalFunction1Height Sensor Ground2-3-4-5Height Sensor Power 6Height Sensor Signal
3.
Circuit diagram ...
